1.Adopt advanced outsize lockstitch sewing, random span quilting, auto thread-breaking checking and pattern amending. The presser foot can be adjusted according to different thickness;
KH shuttle sewing and quilting machine supply for factory
Quilting Width:
≤2400mm
Quilting Thickness:
≤80mm
Rotating Speed of Needle:
2800RPM
Stitch Length:
2-6mm
Capacity:
50-150m/h
Overall Dimension:
10000×3800×1900mm
Total Power:
8.5KW
Power Supply:
380V,50HZ
Total Weight:
2500kg
Application Scope
The Quilting Machine Series produced by Kehua can be used in many fields.Kehua has professional engineers and technicians, so we are able to provide one-stop and comprehensive solutions for customers.
1. KH best sewing machine for quilting and embroidery is developed in our endeavor to provide the highest level of quality.
2. Strict quality inspection procedures throughout the entire production process, must have excellent quality and performance.
3. The product's unparalleled features due to its stable performance and powerful features have been widely praised by customers.
4. Over the years, KH has been growing rapidly in sewing and quilting machine market.
5. Professional after-sales service and technical Q&A are the most solid protection that Foshan City Kehua Smart Quilting Equipment Co.,Ltd. gives to customers.
Product Main Information
2.Windows operating system, can deal with various kinds of complicated patterns precisely;
3.360°jump quilting, large capacity patterns storage system, storage of patterns up to 100 thousand and above;
4.Equipped with functions such as output counting, pattern effect display, processing locus display, auto thread trimming, auto-stop when thread-breaking, etc;
5.Real time data protection, operation continuing in the original position after sudden power shortage;
6.Patterns quilting can be chosen randomly, patterns auto-positioning amending after thread-breaking;
7.Adopt imported servo motors for controlling ensuring better precision and stability;
8.Low noise and vibration, precise operation, stable performance and reliability;
9.Professional pattern-designing software. Scanner-input patterns with BMP format; CAD method pattern designing can be randomly amended and copied;
10.auto-lifting edge-cutting device required processing sizes can be realized in one time, extra cutting is not necessary;
11.Auto cloth-feeding, cutting, less labor.
12. 600 meters extra-long bobbin thread,which is three times as long as the ordinary big rotary hook.
Details of the figure
Patterns figure
Company Features
1. KH dedicates to providing exquisite sewing and quilting machine , further improving the life quality.
2. Foshan City Kehua Smart Quilting Equipment Co.,Ltd. owns strong enough imported technical force to produce best sewing machine for quilting .
3. The service provided by KH is highly reputable in the market. Inquiry! Our desire is to be the leading influential mattress stitching machine supplier in the market. Inquiry! Enterprise culture is the core spirit and strong impetus for KH. Inquiry!
| Model: | 64-2Needles |
| Working Width | 1676mm |
| X Area: | 250mm |
| Sewing Speed: | 400~600n/m |
| Quilting Design: | 360° |
| Rated Voltage: | AC380V |
| Voltage Deviation: | ±4% |
| Power: | 3.5kw |
| Machine Size: | L3800*W1300*H1700(mm) |
.Adopting digital control program.
.X/Y axis by Servo Motor.
.The main axis by Panasonic FCM (Frequency Conversion Motor).
.Prepared some quilting patterns for your choice.
.Easy and quick editing of patterns.
.360°random quilting.
.Function to quilt independent patterns.
.On-line help on operation.
.Speed with 600R.P.M;stitches between 2-6mm adjustable.
.Function of pattern patch-up, can efficiently solve the distorted patterns when quilting the thick materials.
.Simulation display of quilting.
.Automatic needle run-up and orientation brake system.
.Auto-stopping function once thread broken(optional).
.Safe operation under the protector of lnfrared Sensors.
.Adopting the Tensile Motor to control the precision for the quilting Patterns (optional).
