1. Adopt doubled outsize lockstitch sewing, random span quilting, auto thread-breaking checking and pattern amending. The presser foot can be adjusted according to different thickness;
quilting machines machine（slitting device） for workplace KH
Quilting Width:
2400×2600mm
Quilting Thickness:
≤60mm
Rotating Speed of Needle:
2800RPM
Stitch Length:
2-6mm
Capacity:
40-150m/h
Overall Dimension:
9000x4200x2100mm
Total Power:
6.5KW
Power Supply:
380V,50HZ
Total Weight:
1500kg
Application Scope
Kehua 's Quilting Machine Series can be used in multiple scenes.Kehua is dedicated to solving your problems and providing you with one-stop and comprehensive solutions.
1. Advanced technology and latest machine & equipment are used to ensure KH mid arm quilting machines for sale is manufactured based on the requirements of lean production.
2. The product is of a very high standard quality, well-recognized among customers.
3. The product is featured by strong durability and long-lasting performance.
4. Owing to its wade range of application, the product has won many praises from customers.
Product Main Information
2. Windows operating system, can deal with various kinds of complicated patterns precisely;
3. Professional pattern-designing software. Scanner-input patterns with BMP format; CAD method pattern designing can be randomly amended and copied;
4. 360°jump quilting, large capacity patterns storage system, storage of patterns up to 100 thousand and above；
5.Equipped with functions such as output counting, pattern effect display, processing locus display, auto thread trimming, auto-stop when thread-breaking, etc;
6.Real time data protection, operation continuing in the original position after sudden power shortage;
7.Patterns quilting can be chosen randomly, patterns auto-positioning amending after thread-breaking;
8.Adopt imported servo motors, high precision and better stability;
9. Low vibration and noise, accurate, stable and reliable operation;
Details of the figure
Patterns figure
Company Features
1. Foshan City Kehua Smart Quilting Equipment Co.,Ltd. has been a trusted company in the Chinese market. We never fail to deliver high quality mid arm quilting machines for sale .
2. Through the efforts of its excellent R&D team, Foshan City Kehua Smart Quilting Equipment Co.,Ltd. is the young pioneer in quilting machines market.
3. In our company, sustainability is no longer a lofty ideal. We will optimize resource utilization, improve eco-benefits, offer green products and contribute to society to enhance corporate image and sustainability. Ask! We are committed to sustainable practices in all that we do. It dictates how we source materials, how we design and manufacture products, and how those products are shipped and delivered. Sustainability is our promise to the environment. Ask!
Hot To Install
when you installing the machine, there are one box,there are all tools,tape sensors etc,you even no need to use your owen parts/accessories,then can install the machine.for NYL series,need about ONE day on installing
and my side will send you install manual,softwear manual in english.
During this period,if you still have questions, you can video chat with us by whatsapp/skype/wechat/QQ. and send us pictures/video of the issues you meet when installing. we will resolve all of them on time.
Product Description
NYL series is single needle quilting machine,widely used on hometextile industry area,like quilts,pillows,curtains,tablecloths,glove,bedding,mattress etc.
| TYPE | NYL-2628 | NYL-2832 | NYL-3032 | NYL-3535 |
| Quilting size | 2.6X2.8m MAX | 2.8X3.2m MAX | 3.0X3.2m MAX | 3.5X3.5m MAX |
| Needle drop size | 2.4X2.6m MAX | 2.6X3.0m MAX | 2.8X3.0m MAX | 3.3X3.3m MAX |
| Sewing-Machine | Single line style,double line lock style,big rotary,big rotry shttle | |||
| Sewing thick | 1200g/m2 (MAX) | |||
| Sewing Speed | 2000 SPM Stitch 2-7mm | |||
| Needle | SINGLE MR5 18-22# | |||
| Dimensions | 5X4X1.4m | 5.4X4.2X1.4m | 5.5X4.4X1.4m | 5.8X5X1.4m |
| Power | 220V,50HZ,1.5KW (OR per your requirements) | |||
| Weight | 1700kg | 1800kg | 1900kg | 2000kg |
for example: if you choose NYL2628, the max quilting size is 2.6m width and 2.8m length,so you can quilt 2.5x2.8m MAX,and any size under this size like 1.0x1.2m,2.3x2.5m or 0.8x0.6m etc.
Delivery time:
we have all raw material or machine in stock,basically can ship out within 7 days.
Packing:
below are some pictures of products our machine made:
